AC Schnitzer AC1 Complete Wheel Set (7.5x19") - MINI F66 Models

Features of the AC1 Wheel:
- Engineered in Germany
- Weight optimised
- Heat treated
- Developed exclusively for BMW and MINI vehicles
- Equipped with the exclusive AC Schnitzer logo
- 2-year warranty
- Production monitored according to ISO standards

What's included (No Tyres):
- 4x AC1 7.5x19" Wheels
- 4x Spacers & Extended Bolts

What's included (With Tyres):
- 4x AC1 7.5x19" Wheels
- 4x Spacers & Extended Bolts
- 2x Front Tyres (225/35/R19)
- 2x Rear Tyres (225/35/R19)
- 4x TPMS Sensors
Mounted and Balanced

Philosophy/Design
A Generation change for AC Schnitzer wheels, not only the name is new, but also the design - both point to a generational shift in the wheel segment at AC Schnitzer. Although the AC1 wheels are a new design, in one important aspect they pay tribute to their heritage: they too will certainly become a design classic.

With the new AC1 wheels, AC Schnitzer has reinterpreted the classic twin-spoke design. The result is a sporting hybrid look. In a sophisticated style, triangle tips taper towards the wheel edge and widen towards the centre, separated by five trapezoids. These draw the eye directly to the unique classic element of the AC1 wheel: the pentagonal hub cap with AC Schnitzer logo.

Despite this multiplicity of styling elements, the design appears clean and masculine thanks to the very straight lines. The interplay of all these elements gives the AC1 wheel solidity and size.

Material
Only high quality aluminium alloys with the AlSi7 or AlSi11 specification are used.
Both types of material are additionally heat treated in the production process, which results in higher strength and simultaneous weight reduction. Material samples during the production process guarantee the constant and high quality of the material.

Production
A high quality cast blank is the prerequisite for a perfect and durable wheel. AC Schnitzer uses the low pressure casting process for its manufacture. The aluminium alloy is pressed into a multi part casting mould at a pressure of up to 1.2 bar. After cooling to approx 400 degrees Celsius, the mould is opened and the cast blank is ready for further processing.

This takes place during machining and a complex painting process.
X-ray inspections, leak tests and the use of various measuring methods throughout the entire manufacturing process guarantee the consistent and high quality of the wheel.

Bi-Colour Surface
In this process, the wheel is first primed, then completely painted, and finally sealed with an acrylic clear coat. The surfaces that will later have a shiny metallic finish are then machined. Finally, a two-layer clear coat is applied, consisting of a polyester primer and the acrylic clear coat.

Black Surface
In this process, the wheel is first primed, then completely painted. A two-layer clear coat is then applied, consisting of a polyester primer and the acrylic clear coat.

Test Procedures / Safety
After their design, the first sample rims are manufactured under real production conditions. These must undergo a multitude of tests. Among other things, the strength is tested. The "wheel life" is simulated in the bending circumferential test. Every AC Schnitzer wheel must withstand this intact in order to be allowed to be produced and sold at all.

This is followed by vehicle specific tests, including test installations with check of unobstructed movement and driving tests on public roads and on race tracks. Only after these procedures our rims receive their homologation, i.e. the approval to be used in road traffic.

Wheels are safety relevant components. Therefore, they are checked and tested with the greatest care. This starts with the first chemical material tests and ends with hard testing machine endurance runs:

- § 30 StVZO wheel guideline
- ECE R124
- Bending-rotation tests
- 90° impact test
- Unwinding tests
